recycled aggregate of crushed concrete and clay bricks

Recycled aggregate obtained from crushed concrete and clay bricks can serve as a reliable, cost‑effective, and environmentally responsible substitute for natural aggregates in a wide range of construction applications, provided that its production, grading, and quality‑control procedures are carefully managed. Laboratory tests and field trials conducted over the past two decades consistently show that concrete mixes incorporating up to 30 % of such recycled aggregate (by volume) achieve compressive strengths within 10 % of conventional mixes, while the associated reductions in embodied energy and CO₂ emissions range from 15 % to 25 %. Moreover, the use of demolition waste mitigates the depletion of river‑bed sand and gravel, curtails landfill volumes, and aligns with the circular‑economy targets set by many national building codes. The key to realizing these benefits lies in understanding the material’s physical and chemical characteristics, optimizing mix designs, and addressing durability concerns that arise from the presence of adhered mortar and clay minerals.

1. Physical and Chemical Characteristics

Crushed concrete aggregate (CCA) typically consists of broken cement paste, fine aggregates, and residual reinforcement. Its bulk density (2.2–2.4 g cm⁻³) and water absorption (3–7 %) are higher than those of natural coarse aggregate (2.6–2.7 g cm⁻³; 0.5–1 % absorption). The elevated absorption is mainly due to the porous nature of the adhered mortar, which also reduces the aggregate’s apparent strength. Clay‑brick aggregate (CBA), produced by grinding fired bricks, exhibits a lower specific gravity (2.0–2.2 g cm⁻³) and higher water absorption (6–10 %) because of the inherent porosity of the fired clay matrix. Both materials contain silica, alumina, and calcium oxide, but CBA also retains a modest amount of iron oxide, which can impart a reddish hue to the final concrete.

Chemical analyses (XRF, XRD) reveal that the pozzolanic activity of CBA is limited; however, the presence of free lime in CCA can contribute to secondary hydration when sufficient moisture is available. This latent reactivity can be beneficial in mitigating early‑age shrinkage but may also lead to delayed expansion if alkali–silica reaction (ASR) conditions are met. Consequently, the mineralogical composition of the source waste must be screened for deleterious phases such as reactive quartz or high‑alkali brick clays.

2. Mechanical Performance

Numerous experimental programs have quantified the influence of CCA and CBA on concrete strength. Poon and Shui (2004) reported that a concrete mix containing 30 % CCA by volume achieved a 28‑day compressive strength of 31 MPa, compared with 35 MPa for the control mix, while maintaining comparable split‑tensile strength. When CBA was introduced as a partial replacement for fine natural sand (up to 20 % by mass), the compressive strength reduction was limited to 5 % (Kou et al., 2015). The principal mechanisms governing these outcomes are:

• Interfacial transition zone (ITZ) quality: The ITZ between recycled aggregate and new cement paste is typically weaker due to the rough, porous surface of the adhered mortar. Surface treatment (e.g., soaking in saturated lime solution) or the addition of supplementary cementitious materials (SCMs) such as silica fume can densify the ITZ and restore strength.
• Gradation and particle packing: Proper grading of the combined CCA‑CBA blend improves particle packing density, reducing void content and the need for excess cement paste. Optimized gradation often involves blending coarse CCA with fine CBA to achieve a continuous particle‑size distribution.
• Cement content: Increasing the cementitious binder by 5–10 % can compensate for the higher water demand of the recycled aggregates, but this must be balanced against the environmental goal of reducing cement consumption.

3. Durability Considerations

Durability is the principal barrier to widespread adoption. The higher water absorption of CCA and CBA can lead to increased drying shrinkage and susceptibility to freeze–thaw damage. However, studies have shown that when the mix design incorporates a low water‑to‑cement (w/c) ratio (≤0.45) and adequate air entrainment, the freeze–thaw resistance of recycled‑aggregate concrete meets ASTM C666 criteria for 300 cycles (Zhang et al., 2019).

Alkali–silica reaction is another concern, especially when reactive brick clays are present. Mitigation strategies include:

• Low‑alkali cement (≤0.6 % Na₂O equivalent) or the use of pozzolanic SCMs (fly ash, metakaolin) that consume alkalis.
• Pre‑treatment of CBA by washing and drying to remove soluble salts that could accelerate ASR.
• Limiting the proportion of CBA to ≤20 % in the fine‑aggregate fraction when high‑alkali bricks are unavoidable.

Long‑term monitoring of field structures built with recycled aggregates (e.g., the 2012 “Green Bridge” in Shanghai) indicates that carbonation depth and chloride ingress are comparable to conventional concrete when protective cover and curing practices are adhered to.

4. Environmental Impact

Life‑cycle assessment (LCA) models consistently demonstrate that substituting natural aggregates with a 30 % CCA‑CBA blend reduces the global warming potential (GWP) of concrete by 0.12–0.18 t CO₂ eq per cubic meter. The primary contributors to this reduction are:

• Avoided quarrying and transportation of virgin aggregates (≈30 % of aggregate‑related emissions).
• Energy savings from crushing demolition waste (≈15 % of the energy required for producing natural aggregate).
• Landfill diversion, which prevents methane generation from anaerobic decomposition of concrete debris.

When the recycled aggregates are sourced locally (within a 30 km radius), the net GWP reduction can exceed 25 %, making the approach especially attractive for urban redevelopment projects where demolition waste is abundant.

5. Practical Recommendations

To translate laboratory findings into reliable construction practice, the following guidelines are recommended:

1. Source Control: Establish a certification scheme for demolition waste that verifies the absence of hazardous contaminants (e.g., lead‑based paint, asbestos) and quantifies the proportion of mortar versus original aggregate.
2. Processing Standards: Adopt a two‑stage crushing protocol—primary crushing to obtain coarse CCA, followed by secondary grinding to produce fine CBA. Implement sieving to achieve target gradations and remove oversized particles.
3. Quality Assurance: Perform routine tests on the recycled aggregate batch, including specific gravity, water absorption, Los Angeles abrasion, and sulfate resistance. Record these parameters in a material‑traceability log.
4. Mix Design Optimization: Use the “equivalent water” concept to account for the additional water absorbed by the recycled aggregates during mixing. Incorporate SCMs (15–20 % fly ash or slag) to improve workability and durability.
5. Construction Practices: Ensure thorough compaction and adequate curing (minimum 7 days moist curing) to reduce early-age shrinkage. For structures exposed to aggressive environments, consider surface sealers or corrosion‑inhibiting admixtures.

6. Outlook

The convergence of stricter environmental regulations, rising costs of natural aggregates, and growing public awareness of construction waste management positions recycled concrete and clay‑brick aggregate as a strategic resource for the industry. Ongoing research into advanced treatment methods—such as carbonation of CCA to enhance its strength, or the use of nano‑silica to refine the ITZ—promises to further narrow the performance gap with virgin aggregates. Moreover, the integration of digital tracking (blockchain‑based material passports) can provide stakeholders with transparent data on the provenance and performance of recycled aggregates, fostering confidence and facilitating code acceptance.

In summary, when produced under controlled conditions and incorporated with informed mix‑design adjustments, crushed concrete and clay‑brick recycled aggregates deliver mechanical performance and durability that meet the requirements of most structural applications, while delivering measurable environmental benefits. Their adoption not only conserves natural resources but also contributes to the broader goals of sustainable urban development and circular economy implementation.
